Opal Digital, a newly founded Company based in Sulgen Switzerland, works closely with a local Digital Press Manufacturer offering consultation, equipment sales, service and support for digital print solutions throughout Europe

Opal Digital, a newly founded Company based in Sulgen Switzerland, works closely with a local Digital Press Manufacturer offering consultation, equipment sales, service and support for digital print solutions throughout Europe

Opal is dedicated to providing digital print solutions to a wide range of industrial sectors. Our company comprises of highly passionate and experienced personnel with many years’ experience in digital inkjet printing and materials handling equipment, ready to assist with your next project.

Opal Digital is representing the HanGlory Group’s impressive LabStar 330 label press. The press is characterised by an extremely robust and stable platform fully equipped with European components such as servo drives, bearings, controllers, electronics, UV drying, web cleaning, corona and other important elements.

The press is site upgradable from 220mm to 330mm web widths, 5 to 7 colours or from 600 dpi to 1200 dpi. This means that the LabStar 330 can be purchased as an “entry level” unit and later easily expanded to meet its user’s growing processing requirements.

The LabStar 330 is offered as a fully configured comprehensive press ready for use at an attractive price, with ink and maintenance agreements. Prior to delivery all presses are thoroughly tested in Switzerland and only delivered after acceptance by the customer, each machine is equipped with remote monitoring and the customer is supported by Opal Digital if required.   An experienced team of technicians is available for on-site service interventions; the user can count on full service and support. All consumables are supplied from Switzerland. Being in Switzerland, makes Opal Digital the ideal point of contact for customers; ideally for European customers, this means short distances, very easy reachable by driving or flying.



LabStar 330 at a glance – facts and features

Technical Data:

Maximum mechanical speed                      50 m/min

Printing width                                                330mm

Substrate width                                              165 – 350mm

Substrate thickness                                       0.12 – 0.5mm

Electrical supply                                             380v – 50 Hz

Power consumption                                       50 KW

Dimensions                                                      L 6300mm, W 1750mm and H 2000mm

The machine is built and certified to conform with CE Standards



Features:

Unwind and rewind with pneumatic reel lift, 3” shaft, maximum reel diameter 800 mm
Dancing rollers
Web guide with splicing table
Single sided web cleaner with antistatic device
Corona unit

Tension control, web break detector
Optional reinsertion for second pass printing
Section with Kyocera print heads

Pinning after 2 colours
Automatic cleaning of print heads

UV curing unit with servo driven chill roller and water chiller unit

Operator control panel



Benefits:

Field Up-gradable

Print on a wide variety of substrates

Stable high-quality colour

Variable data printing

Solid robust platform



For more information please contact:

Opal Digital Printing Equipment

Industriestrasse 9, CH-8583 Sulgen, Switzerland

Email: info@opal-digital.ch

Web Site: www.opal-digital.ch

Main telephone: +41 71 424 09 80

UK telephone: +44 (0) 7900 570 609
